EXT FERRO E-MX FORK

$2,000.00 USD

Sale Sold out

Taxes included.

Size Flat Crown 19" Wheel Drop Crown 21" Wheel

Quantity

∅36mm hard chromed steel stanchions (heat treated 42CrMo4) with Superfinish surface treatment
Dedicated triple clamp design uppers (7000 aluminium series)
HS3 system: twin positive air system ¬+ 1 large negative self-balancing air chamber, allows to get an optimum level of support through all the travel
Chromed steel air spring shaft with Superfinish surface treatment
High-flow 3-way adjustable cartridge with independent High/Low speed compression and rebound adjustments
External pressure air release system on both legs
Twin hexagonal floating axle, boost compatible ∅20mm
Air spring and cartridge radial guide system with bespoke aeronautical seals (minimize friction on side loads)
Large piston design for best damping control and separate IFP/coil energized compression valve
No cavitation and low hysteresis
Self-hydraulic cartridge bleeding
Dedicated Mobile Sliding DU guiding system with super-long static overlap (for maximum guidance and best torsional rigidity). (CGB Continuously Guided Bushing system, increase stiffness)
205 mm of travel and 44 mm offset
200 mm post mount brake
Weight 4000gr
Pressure release one way valves on both legs
